Voltage drop / Cable size /SC - Free Download

Version : 1.0.1 Oct2019
Features :
- AWG AND Metric.
- Voltage drop calculator.
- Cable size calculator.
-Short Circuits Calculators
-Voltage Drop Tables.
- Short Circuit tables.
- Temperature correction factor in air .
- Ground temperature correction factor .
- Soil Correction factor .
- Thermal correction factor .
- Cable distance correction factor .
- Cable depth correction factor.
- Cable grouping factor.
- Cables construction.
- Voltage drop for single core LV cables (Copper).
- Voltage drop for Multi-core LV cables (Copper).
- Voltage drop for single core LV cables (Aluminium).
- Voltage drop for multi-core LV cables(Aluminium).
- PVC vs XLPE cables.
- Selecting a power cable.
- KA short circuit current - copper conductor- PVC insulated.
- KA short circuit current - copper conductor- XLPE insulated.
- KA short circuit current - Aluminium conductor- PVC insulated.
- KA short circuit current - Aluminium conductor- XLPE insulated.
